on floppy adpll, this time, my solution

This isn’t by any stretch finished, but it does do what I’ve expected it to do.

It responds both to differences in phase (counter is set to 0), and differences in frequency (period is adjusted in the direction of the frequency error)

I did this at 3am last night, so there could be a couple bugs in there.

With all this being said, I’m not entirely sure that PLLs are actually required for good reading of amiga floppy disks. My regular “static interval” solution works about 95%-98% of the time. I’m going to come up with a list of problem disks and see if this solution works better/worse/otherwise.

I’ve used a read data window of 1us, which starts being centered on 2us, and is automatically adjusted as data comes in. This produces windows around 2us, 4us, 6us, 8us. I output the overall error which is the deviation from the center of the window as each pulse is received. I’d like to graph this error, but it doesn’t look like Xilinx’s iSim will export a particular output as CSV or whatever.

module floppy_pll(
    input clk,
    input floppy_data,
     input reset,
    output reg window_open,
    output reg [7:0] data,
    output reg strobe,
     output reg [7:0] error
    );

// window is 1us wide
// starts at .5us before counter rollover
// ends .5us after counter rollover
// ideally, edges should be arriving right when the counter rolls over

reg [7:0] period = 100;
reg [10:0] counter = 0;

reg IN_D1, IN_D2;
wire out_negedge = ~IN_D1 & IN_D2;

always@(posedge clk or posedge out_negedge) begin

    if (reset) period <= 100;

    if (clk) begin

        counter <= counter + 1;
        if (counter == period) counter <= 0;

        if ( (counter > (period-25)) || (counter < 25) ) window_open <= 1;
        else window_open <= 0;

    end

    if (out_negedge) begin

        // if counter == 0 and we see out_negedge be positive, then we are perfectly aligned
        // so we dont need to adjust anything
        if (counter != 0) begin

            if (window_open) begin

                counter <= 0; // align counter to the phase of the incoming signal

                if (counter < 25) begin

                    //we rolled over before pulse was seen, so make period larger
                    //error values will be over 128
                    period <= period + 1;
                    error <= (128 + counter);

                end

                if (counter > (period-25)) begin

                    //we haven't rolled when we saw the pulse, so make period shorter
                    //error values will be less than 128

                    period <= period - 1;
                    error <= 128 - (period-counter);

                end

            end

        end

    end


    // edge detection flops for data in direct from floppy
    IN_D1 <= floppy_data;
    IN_D2 <= IN_D1;
end

endmodule

results from adding the PJL

So, as I mentioned in another post, I added Jim Thompson’s phase-jerked-loop to the project.  Phil had good luck using it with his DiscFerret, but it really didn’t help me.  My problem disks are still problem disks.  And the data returned as a result still have the same problem.

This PJL really didn’t help me.

http://www.analog-innovations.com/SED/FloppyDataExtractor.pdf

I expected the numbers to look a little more stable —- as if we are tracking them better, but I really just didn’t see this.

I’m planning on reverting my changes soon unless some more playing around will help.

motor speed variation tests

I collected roughly 1,000 index pulses from the Sony MPF920-E with one common floppy inserted.

The motor speed variation was very very small.  I am impressed as to the accuracy.

Across 967 index pulses, all were within 56 microseconds of each other.  The average was 200.487ms.  Most of the group were within 20 microseconds of the average.

The standard deviation is 9.46 microseconds.

on recent disk reading results

(this was posted to Classic Computer mailing list, please disregard if you’re on the list.  I think this is an important topic)

The last two nights I’ve been busy archiving some of my Amiga floppy collection.  Most disks were written over 20 years ago.

On a sample size of about 150 floppies, most of them were perfectly readable by my homegrown usb external amiga floppy drive controller.

I paid very close attention to the failures or ones where my controller struggled.

Without sounding too obvious here, the time between the pulses (which more or less define the data) were grossly out of spec.  The DD pulses should nominally be 4us, 6us, and 8us apart before pre-write compensation.  Most good disks are slightly faster, and normal times for these ranges are:

4us: 3.2-4.2us.  Many around 3.75us
6us: 5.5-6.2us.
8us: 7.5-8.2us

(notice margins around 1-1.3us)

My original microcontroller implementation was 3.2-4.2, 5.2-6.2, and 7.2-8.2.

When my current FPGA controller would have a problem, I’d notice that there were problems right on a boundary.  So maybe pulses were coming in at 3.1us apart instead of 3.2.  Or maybe 4.3 instead of 4.2.  So I kept bumping the intervals apart, making a larger range of pulse times acceptable — the XOR sector checksums were passing, so I was likely making the right choices.  The bits were ending up in the right buckets.

But as I went through some of these disks, I ended up with the difference between ranges(and basically my noise margin) being reduced smaller and smaller.  Some to the point where an incoming pulse time might fall darn smack in the middle of the noise margin.  Which bucket does THAT one go into?

My approach has been very successful(easily 95%+), but it makes me wonder about Phil’s DiscFerret dynamic adaptive approach where a sample of the incoming data defines the ranges.

Some disk drives and controllers might be faster or slower than others, and if you create custom ranges for each disk (each track?), perhaps you’ll have better luck.

more real world tests

So tonight, I put my new FPGA implementation of the amiga floppy project to good use.  I read some more of my collection of amiga floppies.

GREAT NEWS.

It’s working like a champ.  As a matter of fact, I selected disks which I could not previously read with my microcontroller solution.  I could read 90% of the previously unreadable ones.  Most of the unsolvable problems were related with HD disks (which, based on my earlier posts, some drives handle better than others)  Note this is just temporary until I try other drivers to read the disks — and try covering the HD hole.

I have better visibility on the PC as to the “problem” delta T’s.  So pulses that are slightly too far apart, just on the boundary of what I consider to be valid, if I adjust my boundary accordingly, and now consider them valid, everything is peachy-keen.  I want to add a real-time option in my java client to allow this to be adjusted on the fly.  See problems? Adjust the slider, and problems go away.  Pretty neat.

I didn’t have this visibility when the microcontroller was interpreting the delta T’s.  The microcontroller had no easy feedback method to tell me what was happening.  Having high-level debugging of the information on the PC makes this all possible.

Nice to see the software purring.  There is still plenty of improvements to make, usability to be improved, etc.  But its working very nicely.

characterizing speed performance of floppy drive controller

So I’ve got things working rather swimmingly right now.  Switched drives from Samsung to Sony, and it’s made a huge difference.  The Sony just seems to work better.

I’m averaging about 355ms per track, yielding 57s total disk times.  The 355ms is made up of 313ms of transfer time at an effective throughput rate on the serial of around 1.175mbps.  Which is basically 1.5mbps baud rate, theoretical max of 1.2mbps.  This isn’t horrible performance, but I really want to get back to 2mbps.  I haven’t been using 2mbps because I have massive errors, but I think that there is some round off happening in my UART that prevents it from working correctly.  I need to revisit my UART code and find out exactly why 2mbps doesn’t work.  I’ve run this usb->ttl converter at 2mbps with my uC, so it really should work fine.

If I go to 2mbps, I’ll EASILY chop off the 88ms from 313ms, and I’ll be transferring the track to the PC in REAL TIME.  Basically, as fast as I receive it, I’ll be sending it to the PC.  Remember, that because I transmit the pulse times, and not the data, that fast times are really required.  This is a little more complicated than just saying the RAW MFM rate is 500kbps, so you need 500kbps of bandwidth to the PC.

There are several optimizations I can do, and I’ll post more later.

working FPGA version of the amiga floppy project

So, I’ve been working on the FPGA version of the amiga floppy project for some time.  I just recently had a fair bit of free time, and so everything came together rather quickly!

I’m now able to read amiga floppy disks in using the same Java client software I had developed for use with the Parallax SX microcontroller board.  There were a few minor changes in the software — most notably the read data routine from the hardware.

I’ve written the code in Verilog on a Xilinx Spartan-3e evaluation board.

The various hardware parts I’ve described:

  • UART: Written from scratch, a transmitter and a receiver.   Simple to use, variable baud rates.
  • FIFO: Generated from Xilinx’s CoreGen. This connects the floppy interface to the USB interface. 32k bytes
  • FSM to always empty the FIFO to the PC.  Once something goes in the FIFO, it immediately gets sent to the PC
  • Read-floppy-FSM: Stores 225ms of Delta T’s (aka time between edges) as 8-bit integers into the FIFO.
  • Command FSM: Receives single-character commands from the java software to execute (R for read, U for upper head, L for lower head, etc)
  • Transmit test pattern routine: Sends 32k of data to the PC to test for reliable communication

A couple advantages with the FPGA solution:

  • We transmit the data to the PC as soon as it’s available.  I want to characterize the actual latency, but it should be pretty small.  This is different from my load->FRAM, and then FRAM-> PC method.  This method should be much faster and we’re just not idling for 225ms.
  • Instead of transmitting the bit-sync’d raw MFM to the PC, I’m sending the delta T’s.  While this requires a little more processing on PC, the PC can more easily determine why a particularly sector can’t be read.  For instance, is the time between pulses too small? Too large?  On a fringe edge?  Plus, since the Java decodes these, I can now add sliders for “acceptable delta T’s” for each 4, 6, or 8us windows.  Before that would require modifying the firmware on the microcontroller.  I can also start to do statistical analysis on the pulse times.

I am currently doing about 430ms per track.  This sucks.  I was beating that by 100ms with my microcontroller.  However, the problem is that because a variable amount of data is going to the PC, the PC receiving code does not know when exactly to stop receiving, so there’s a wait-timer which I have to optimize.  Once I receive the minimum amount of data, I wait 100ms since the last received data, and then exit.  I’ve got to put my logic analyzers in place and figure out how to optimize it.

Denis@h3q can read a disk in 43s, which is pretty darn good.  He is using tokens like I mentioned here and here and here.  I’m transferring much more data though, which gives me more information.  I like his time, and maybe that would be a nice goal to beat!  Wow. That’s only 269ms/track.  Hrrrmm…. that’s pretty good.

Histogram of one track

Here’s a histogram of one track off an amiga floppy disk.  Notice the peaks near 4us, 6us, and 8us.

histo788

I’ve got this data from my logic analyzer, crunched through my little C proggie, and then graphed with Excel.

This shows roughly 45,000 delta Ts, the time between each transition.  The first group, of course, the ’10’s, second ‘100’s and the third, ‘1000’s.

bought a Saleae Logic. Another tool for my toolbox

logic

I bought at Saleae Logic which is an inexpensive logic analyzer.  See link here.

It isn’t nearly as fast (only samples at 24mhz max), and it doesn’t have as advanced triggering capabilities, but it does do millions->billions of samples.

So, of course, I put it to the test!  I recorded 5 million samples at 24mhz which works out to be 210ms, just slightly over a floppy track time of 203ms.  I sampled an entire track, which is FANTASTIC if you know anything about logic analyzers.  They just don’t usually store much.

Then I wrote a small C program which converts the exported binary data to RAW AMIGA MFM.  I searched for binary patterns of the sync code 0x94489, and exactly 11 of them came up.  Which means that my little code is working, the logic analyzer is correctly reading the data.  I still have to try to decode this track and see if it decodes properly, but this is pretty neat.  It’s like third party verification of what I’m doing.

I have these odd exception cases where sometimes a track refuses to read although the amiga reads it perfectly.  I’m going to get the bottom of those cases.

I hate to say this, but everything just worked tonight.  No problems. Brought back up the java client, programmed the SX, and off I went.  Pretty neat.

I’ll have more to say on this logic analyzer, but the software is really nice, clean, simple.  It does its job.

I can’t tell you for how long I’ve wanted to sample a whole track w/ some test equipment.  You can buy $$$ logic analyzers and not get this type of buffer space…. It achieves it by doing real-time samples straight to the PC’s ram……

FPGA eval board

One of these arrived today.  Very cool.  I’ve only done minor things with it so far — but I’m learning.

I’ve got FPGAs by Example for Verilog coming within a couple days.  Looks like a good book.

The only thing I’ve managed to do so far was modify the assembly for the picoblaze microcontroller to change the text scrolling on the lcd — you’ve got to start some place.

So is this amiga floppy project rev 3 now? heh. I dunno.

(I want to get the afp stable, working perfectly, and move on — I’ve spent too much time on it already, although I’ve enjoyed every minute)
